The Powermax105® plasma system has the duty cycle and performance needed for tough industrial cutting and gouging jobs.
Delivering superior clean cut capabilities on 32 mm (1-1/4") thick metals, it also offers the latest technological innovations, such as Smart Sense™ technology to automatically adjust the gas pressure.
Seven Duramax™ torch styles provide versatility for hand cutting, portable automation, X-Y table cutting, and robotic cutting and gouging.
Has Output Port For CNC Plasma Tables
Maximum productivity
Finish jobs faster with cut speeds three times greater than oxyfuel on 12 mm (1/2") mild steel
Superior cut and gouge quality let you spend less time on grinding and edge preparation
Multiple, easy-to-use torch styles let you tackle a wide variety of jobs using the same system
Easy-to-use for cutting and gouging
No need to change the air pressure – Smart Sense technology ensures that it is always correctly set; it also detects electrode end-of-life, automatically turning off power to the torch to prevent potential damage to other parts or to the workpiece
SpringStart™ technology ensures consistent starting and a more reliable torch
Drag cut at full output with a patented shield that reduces dross buildup for smoother cutting
Built to handle tough jobs
Hypertherm Certified™ reliability ensures peak performance even in the harshest environments
Duramax torches are designed for high-impact and heat resistance
Cut capacity
Capacity
Thickness
Cut speed
Cutting
Recommended
32 mm (1-1/4″)
500 mm/min (20 ipm)
38 mm (1-1/2″)
250 mm/min (10 ipm)
Severance (hand cutting)
50 mm (2″)
125 mm/min (5 ipm)
Pierce *
22 mm (7/8″)
Specification:
Input voltages
CSA
200-600 V, 3-PH, 50/60 Hz
CE
400 V, 3-PH, 50/60 Hz 200-400 V, 3-PH, 50/60 Hz
CCC
380 V, 3-PH, 50/60 Hz
Input current @ 16.8 kW
200/208/240/380/400/480/600 V, 58/56/49/28/25/22 A
Output current
30 - 105 A
Rated output voltage
160 VDC
Duty cycle @ 40°C (104°F)
80% @ 105 A
Open circuit voltage (OCV)
200-600 V CSA: 300 VDC
380 V CCC and 230-400 V CE: 288 VDC
400 V CE: 292 VDC
Dimensions with handles
592 mm D; 274 mm W; 508 mm H (23.3" D; 10.8" W; 20.0" H)
Weight with 7.6 m (25') torch
200-600 V CSA: 45 kg (100 lbs)
380 V CCC/400 V CE: 41 kg (90.4 lbs)
230-400 V CE: 45 kg (100 lbs)
Gas Supply
Clean, dry, oil-free air or nitrogen
Recommended gas inlet flow rate / pressure
Cutting: 217 l/min (460 scfh) @5.9 bar (85 psi) Gouging: 227 l/min (480 scfh) @4.8 bar (70 psi)
Input power cable length
3 m (10') *
Power supply type
Inverter - IGBT
Engine drive requirement
30 kW for full 105 A output
Certifications
CSA-certified for use in the Americas and Asia, except China. CE, C-Tick, CU/GOST, Ukr, and Serbian — for use in Europe, Australia, Belarus, Kazakhstan, Russia, Serbia, Ukraine, and other countries where accepted. CCC for use in China.
Warranty
Power supplies have a 3-year warranty and torches a 1-year warranty.
